 IGMP Proxy - If you want to watch TV through IGMP, please Enable it.
Click the Save button to save your settings.

Note:
1) If you change the IP Address of LAN, you must use the new IP Address to log in the router.
2) If the new LAN IP Address you set is not in the same subnet, the IP Address pool of the
DHCP server will change accordingly at the same time, while the Virtual Server and DMZ
Host will not take effect until they are re-configured.
3.4.3 Wireless
There are six submenus under the Wireless menu: Wireless Settings, WPS, Wireless
Security, Wireless MAC Filtering, Wireless Advanced and Wireless Statistics. Click any of
them, and you will be able to configure the corresponding functions.

3.4.3.1. Wireless Settings

Go to "Advanced→Wireless→Wireless Settings", you can configure the basic settings for the
wireless network of 2.4GHz on this page.
TL-WR841HP 300Mbps High Power Wireless N Router
-34-
