5.2.2 SYNTHESIS 14-18kVA

Operating Temperature Range: 0 - 40°C (32 - 104°F)
Unit Size (kVA)
Heat Rejection
(BTU/Hr)
Weight (LBS)
(Std unit w/o
Battery)
Width
Depth
Height

6.0 Spare Parts Listing

6.1

4-6 kVA SPARE PARTS LISTING

4-6 kVA - Level 1
KIT P/N: SPK6KL1
Qty. Part number
2 10B46436PB32
2 10B46436PC40U
5 10B46347P001
5 10B46209P05R
5 10B46209P11R
2 00B46030PF05T
4-6 kVA – Level 2
KIT P/N: SPK6KL2
Qty. Part number
1 10B44112P0506
1 10B44112P0512
1 10B44114P01
1 10B44087P2
2 00B44074PT112
2 10B48270P1
4-6kVA – Level 3
KIT P/N: SPK6KL3
Qty. Part number
1 15B10722G1
1 15B10602G1
1 15B10604G1
1 15B10606G3
1 15B10724G1**
(Temperatures above 25°C (77 °F) shorten battery life
and affect system warranty)
Cooling: Forced Air
14.0 16.0
7340 8389
43.4
25.6
42.1
CIRCUIT DESIGNATION
FU3, FU6
QS5
FU7, FU8
FU9
FU3, FU6 (AP1)
FU1 (AP2)
CIRCUIT DESIGNATION
V5
V7
V4
V6
V3,V8,V9
EV1
CIRCUIT DESIGNATION
AP4
AP5
AP2
AP1
AP3
54
18.0
9437
Description
32 A Fuse, Extra Fast
40 A Fuse, Extra Fast
Fuse, 1A, 250V, Delayed
Fuse, 2A, 500V, Delayed
Fuse, 8A, 500V, Delayed
1 A Fuse, Delayed
Description
IGBT, 2 x 50A 600 V
IGBT, 2 x 50A 1200 V
SCR, 40A, 1200V
Diode, ultra-fast, 2 x 30A
SCR, 25A, 1200V
Fan, EDP 50
Description
Micro board
Boost board, 6K
Inverter board, 6K
Charger board, 6K
Front panel board, 6K
