1.5.8 BATTERY CABINET PLACEMENT

Remove the strapping, mounting screws, enclosure, and all packing material from the
Battery Cabinet. Attach the ramp to the front of the pallet and roll the unit down the ramp.

1.5.9 ELECTRONICS MODULE PLACEMENT

Remove the strapping, mounting screws, wooden enclosure, and all packing material from
the Electronics Module. Attach the ramp to the front of the pallet and roll the unit down the
ramp.
Check the nameplate on the rear of the Electronics Module to verify that the power rating
and the line and load voltages correspond to the order.

1.5.10 OUTPUT CABINET PLACEMENT (4-12kVA)

Remove the strapping, cardboard enclosure, and all packing material from the Output
Cabinet. Attach the ramp to the front of the pallet and roll the unit down the ramp.

1.6 ELECTRICAL CONNECTIONS (4-12kVA)

•
Connections to the building electrical system should utilize flexible raceway to
allow movement of the cabinet for service access.
•
All cabinets should be bonded to comply with applicable NEC Requirements.
•
Torque terminal screws to 20 in-lbs.
•
Electrical connections are made at the rear of the Electronics Cabinet, at the
front of the output cabinet (4-6kVA), at the rear of the Output Cabinet (8-12kVA,
and at the rear of the Battery Cabinet (if present).
NOTE:
Battery Inter-Shelf
connectors should not be
joined until you are ready to
perform the system start-up
procedure. See Section
1.6.2 or 1.7.2.
NOTE:
Save shipping materials of all cabinets
until final testing is complete.
