2.0 CONTROLS AND OPERATION

2.1 INTRODUCTION

The following instructions provide complete system start-up and operation procedures. It is
important to note that in performing some of these procedures the buzzer may sound. This
will happen each time the system goes into its emergency mode operation or if the battery
voltage drops to approximately 150 volts. Pressing the alarm silence button silences the
buzzer, see Section 2.2.
If at any time during these procedures a problem occurs, refer to

CONTROL PANEL

2.2

2.2.1 COMMANDS AND SIGNALS

Synthesis comes complete with a control panel on the front of the
UPS, which provides visual (LED) and audible indications of the
current condition of the supply to the load.

2.2.2 VISUAL INDICATIONS

The visual indications are in three different colors that are
associated with a set of easy to understand symbols.
NOTE: For a description of the significance of the visual indications see Table

2.2.3 COMMAND BUTTONS

These buttons allow the activation of the following commands:
Silence Audible Alarm: pressing this button deactivates the
Inverter On: pressing this button activates the inverter
Inverter Off: pressing this button stops the inverter.
NOTE: Pressing of the Inverter On and Silence Acoustic Alarm buttons
simultaneously activates the manual battery test.
NOTE:
Section 3.4: Troubleshooting Procedures.
LED 1 LED 2
Red Yellow
audible alarm (buzzer)
To avoid accidental stopping of the inverter, this
button must be pressed for at least 2 seconds.
31
LED 3
Green
.
D
