5.1.2 SYNTHESIS 14-18kVA

(At 25 °C, Nominal Line Voltage unless otherwise specified)
Output Power (kVA/kW):
Input Voltage:
Output Voltage:
Output Frequency:
Output Voltage Regulation:
(Static)
Dynamic Output Voltage
Regulation:
(Over Static Regulation)
Charging Current:
Efficiency:
Line Interactive Mode:
Double Conversion Mode:

5.2 MECHANICAL

5.2.1 SYNTHESIS 4-12kVA

Operating Temperature Range: 0 - 40°C (32 - 104°F)
Cooling:
Unit Size (kVA)
Heat Rejection
(BTU/Hr)
Weight (LBS)
(Std unit w/o Battery)
Dimensions:
Width
Depth
Height
14/9.8, 16/11.2, 18/12.6
208 or 240 VAC, 60 Hz, Single Phase Factory Wired
120/208/240V Single Phase Factory Wired
60 Hz ± 0.05%
± 6%
5% (0-100% AND 100%-0 Load
Variation)
3A
Measured at Rated Load, 0.7 pf
95%
82%
(Temperatures above 25°C (77 °F) shorten battery life
and affect system warranty)
Forced Air
4.0 5.0 6.0
1430 1790 2140
245 245 245
24.3" 24.3" 24.3"
23.6" 23.6" 23.6"
30.3" 30.3" 30.3"
53
8.0 10.0 12.0
2600 3250 3900
310 310 310
29.8" 29.8" 29.8"
29.5" 29.5" 29.5"
37.8" 37.8" 37.8"
