1.7.3 CONNECTION OF THE LOAD WIRING (14-18KVA)

Make sure the labeled output voltage corresponds to the rated load voltage. Make the
appropriate connections as detailed in the following sections.
1.7.3.1 CONNECTIONS FOR 120/208/240V LOADS (14-18kVA)
Connections for 240VAC loads are available between L3 and L4, Figure Q. Loads that
utilize 208V can be connected using terminals L5 and L6, Figure R. Use L3 and N and/or
L4 and N for 120VAC loads, Figure Q. Ensure that the loads are evenly balanced
between L3 and N and L4 and N. The total kW drawn from these connections cannot
exceed the kW rating of the UPS. All reference figures are located in section 1.7.1.

1.7.4 LEVELING THE CABINETS

After all connections have been completed adjust leveling feet to lift casters off of floor and
immobilize cabinets. See Section 1.6.6.
NOTE
This equipment is manufactured as a
separately derived system. The output
neutral shall be grounded in accordance
with NEC Art 250-5.
