5.0 Specifications

5.1 ELECTRICAL

5.1.1 SYNTHESIS 4-12kVA

(At 25 °C, Nominal Line Voltage unless otherwise specified)
Output Power (kVA/kW):
Input Voltage:
Output Voltage:
Output Frequency:
Output Voltage Regulation:
(Static)
Dynamic Output Voltage
Regulation:
(Over Static Regulation)
Charging Current:
Efficiency:
Line Interactive Mode:
Double Conversion Mode:
4/2.8, 5/3.5, 6/4.2, 8/5.6, 10/7, 12/8.4
208* or 240 VAC, 60 Hz, Single Phase Factory Wired
*NOT AVAILABLE ON 6kVA or 12kVA SYSTEMS
120/208/240V Single Phase Factory Wired
60 Hz ± 0.05%
± 6%
5% (0-100% AND 100%-0 Load
Variation)
1A (4-6kVA)
2A (8-12kVA)
Measured at Rated Load, 0.7 pf
93%
87% (4-6kVA)
88% (8-12kVA)
