4.0 AUXILIARY AND OPTIONAL EQUIPMENT

This section provides descriptions of the auxiliary and optional equipment available on the
Synthesis™ Uninterruptible Power Supply system. Some options are factory installed and
the user installs others. Interconnection wiring instructions are provided where necessary.
UPS module connections are made at the rear of the cabinet. See Figure Z or AA for
connector locations.
SW1 SW2
F7 F8
8-12 kVA
Figure Z: UPS Module Interface Connector Locations 4-12kVA. (Back of Unit)
RS-232 INTERFACE
REMOTE EPO
TERMINAL
RS-232
(USED BY FRONT
PANEL DISPLAY)
SUMMARY ALARM
TM
AS/400

INTERFACE

DIP SWITCHES
Figure AA: UPS Module Interface Connector Locations 14-18kVA. (Back of Unit)
4.1 INTERFACE

4.1.1 DISPLAY

The back-lit liquid crystal alphanumeric display has a total of 24 characters arranged in
two lines; it provides a means of communication with Synthesis™ through display of
operating parameters and measured values.
RS232
COMPUTE
Remote
(Used by front
R I NTERFA
panel display)
CE
TM
SUMMAR
Y
ALAR
M
39
RS232
EPO
Port
MODEM
POWER
SUPPLY
F8
F7
4-6 kVA
