TABLE OPERATIONAL STATUS OF CONTROL PANEL INDICATORS
D
LED 1 LED 2 LED 3
Red yellow green
Off Off ON
Off Off Flashing
Off Flashing ON
Off ON Flashing
Off ON Off
ON ON Off
ON Off Off
Flashing Flashing Flashing
ACOUSTIC STATUS
ALARM
Silent Normal
Silent Normal
Active WARNING
Active WARNING
Active WARNING
Active FAILURE
Active FAILURE
Active TEST
NOTE:
Only qualified personnel should operate this
equipment. Refer to Figure V or Y for switch
locations.
32
COMMENT/
REASONS
Normal Operation
Not functioning in
accordance with assigned
priority.
Battery supplying load:
the battery is discharging
Load supplied by low
priority source, because
high priority source is
unavailable.
UPS operating outside
permitted parameters.
UPS supplying load with
INVERTER OFF.
UPS supplying load in
pre-alarm condition (e.g.
high ambient temperature
or mains interruption)
UPS supplying load, with
battery switch OPEN.
UPS supplying load, with
blown fuses (mounted
inside battery switch).
UPS supplying load with
faulty batteries.
Load NOT supplied due
to output switch OPEN.
Load NOT supplied due
to serious UPS
malfunction.
UPS self test in progress.
ACTIONS
None
None
Silence the acoustic alarm.
If the condition persists,
acoustic alarm will begin
again towards the end of
autonomy and, in a short
time, the UPS will switch
OFF.
Ensure that power supply to
UPS is present. Verify the
status of the protection
devices upstream of UPS.
If the condition persists for
more than 24 hours, call the
Customer Service Center.
Start INVERTER by
pressing appropriate button.
If the condition persists for
more than 24 hours contact
the Customer Service
Center.
Close battery switch.
Check fuses
Call Customer Service
Center as soon as possible.
Close output switch
Call Customer Service
Center as soon as possible.
None: This happens
automatically whenever
UPS is switched on.
