5-19-6 SIGNED BINARY COMPARE – CPS(––)
Description
286
ER: One of the tables (i.e., TB1 through TB1+15, or TB2 through TB2+15)
exceeds the data area.
Indirectly addressed EM/DM word is non-existent.
(Content of *EM/*DM word is not BCD, or the EM/DM area boundary
has been exceeded.)
EQ: ON if the entire contents of both tables are equal and R=0000.
The following example shows the comparisons made and the results provided
for MCMP(19). Here, the comparison is made during each cycle when 00000
is ON.
TB1: IR 100
0100
0200
0210
ABCD
ABCD
ABCD
ABCD
0800
0900
1000
ABCD
ABCD
ABCD
1400
0210
1212
Ladder Symbols
CPS(−−)
Cp1
Cp2
000
When the execution condition is OFF, CPS(––) is not executed. When the exe-
cution condition is ON, CPS(––) compares the 16-bit (4-digit) signed binary
contents in Cp1 and Cp2 and outputs the result to the GR, EQ, and LE flags in
the SR area.
Address Instruction
MCMP(19)
00000
100
00001
DM 0200
DM 0300
TB2: DM 0200
DM 0200 0100
DM 0201 0200
DM 0202 0210
DM 0203 0400
DM 0204 0500
DM 0205 0600
DM 0206 0700
DM 0207 0800
DM 0208 0900
DM 0209 1000
DM 0210 0210
DM 0211 1200
DM 0212 1300
DM 0213 1400
DM 0214 0210
DM 0215 1600
IR, SR, AR, DM, EM, HR, TIM/CNT, LR, #
IR, SR, AR, DM, EM, HR, TIM/CNT, LR, #
Section 5-19
Operands
LD 00000
MCMP(19)
DM 0200
DM 0300
R: DM 0300
DM 030000 0
DM 030001 0
DM 030002 0
DM 030003 1
DM 030004 1
DM 030005 1
DM 030006 1
DM 030007 0
DM 030008 0
DM 030009 0
DM 030010 1
DM 030011 1
DM 030012 1
DM 030013 0
DM 030014 0
DM 030015 1
Operand Data Areas
Cp1: First compare word
Cp2: Second compare word
000
Not used. Set to 000.
100
