Omron CQM1H - PROGRAM Programming Manual page 506

Cycle Time
Code Mnemonic ON execution
time (µs)
13 DIFU 16.2
14 DIFD 15.6
15 TIMH
27.4
27.4
16 WSFT 33.6
57.8
1.7 ms
9.8 ms
20 CMP 20.1
22.2
58.0
21 MOV 17.7
19.8
54.6
22 MVN 17.8
19.9
54.5
23 BIN 37.8
72.0
24 BCD 35.8
70.0
25 ASL 18.0
34.4
26 ASR 18.0
34.4
27 ROL 18.6
35.0
28 ROR 18.6
35.0
29 COM 19.5
36.3
30 ADD 37.5
39.9
91.6
31 SUB 37.5
39.8
91.6
32 MUL 55.3
57.8
108.4
33 DIV 54.2
56.6
107.3
34 ANDW 31.5
33.9
85.6
Conditions (Top: min.; bottom: max.)
Any
Any
Constant for SV
*DM for SV
With 1-word shift register
With 10-word shift register
With 1,024-word shift register using *DM
With 6,144-word shift register using *DM
When comparing a constant to a word
When comparing two words
When comparing two *DM
When transferring a constant to a word
When moving from one word to another
When transferring *DM to *DM
When transferring a constant to a word
When moving from one word to another
When transferring *DM to *DM
When converting a word to a word
When converting *DM to *DM
When converting a word to a word
When converting *DM to *DM
When shifting a word
When shifting *DM
When shifting a word
When shifting *DM
When rotating a word
When rotating *DM
When rotating a word
When rotating *DM
When inverting a word
When inverting *DM
Constant + word → word
Word + word → word
*DM + *DM → *DM
Constant – word → word
Word – word → word
*DM – *DM → *DM
Constant × word → word
Word × word → word
*DM × *DM → *DM
Word ÷ constant → word
word ÷ word → word
*DM ÷ *DM → *DM
Constant ∩ word → word
Word ∩ word → word
*DM ∩ *DM → *DM
Section 7-3
OFF execution time (µs)
Normal IL JMP
15.8 15.5 13.4
Normal IL JMP
15.6 15.5 13.3
Reset IL JMP
41.2 40.0 20.8
60.6 59.4 20.8
1.5
1.5
1.5
1.5
1.5
1.5
1.125
1.125
1.125
1.125
1.125
1.875
1.875
1.875
1.875
1.875
481
