Memory Areas
Analog I/O Board Flags/Bits
Word Bits
IR 232 00 to 15 Analog Input 1 Conversion Value
IR 233 00 to 15 Analog Input 2 Conversion Value
IR 234 00 to 15 Analog Input 3 Conversion Value
IR 235 00 to 15 Analog Input 4 Conversion Value
IR 236 00 to 15 Analog Output 1 SV
IR 237 00 to 15 Analog Output 2 SV
IR 236 to IR 243 00 to 15 Not used.
Analog Setting Board (Slot 1 and 2) Flags/Bits
Word Bits
IR 220 00 to 15 Analog SV 1: 0000 to 0200 (4-digit BCD)
IR 221 00 to 15 Analog SV 2: 0000 to 0200 (4-digit BCD)
IR 222 00 to 15 Analog SV 3: 0000 to 0200 (4-digit BCD)
IR 223 00 to 15 Analog SV 4: 0000 to 0200 (4-digit BCD)
Flags/Bits for Communications Units
Controller Link Status
Area 1 (IR 090 to IR 095)
Word Bits
IR 090 00 to 14 Always 0
15 Local Node's Data Link Participation Status
0: The local node not in the Data Link or Data Link is stopped.
1: The local node is participating in the Data Link.
IR 091 00 to 07 Data Link Status: Node 1
08 to 15 Data Link Status: Node 2
IR 092 00 to 07 Data Link Status: Node 3
08 to 15 Data Link Status: Node 4
IR 093 00 to 07 Data Link Status: Node 5
08 to 15 Data Link Status: Node 6
IR 094 00 to 15 Not used.
IR 095 00 to 10 Always 0
11 Terminator Status
0: Terminating resistance switch OFF
1: Terminating resistance switch ON
12 to 15 Always 0
