Omron CQM1H - PROGRAM Programming Manual page 178

IR Area
I/O Words Required
by I/O Units
Name I/O
points
DC Input 8 CQM1-ID211
Units
16 CQM1-ID111
CQM1-ID212
32 CQM1-ID112
CQM1-ID213
CQM1-ID214
AC Input 8 CQM1-IA121
Units
CQM1-IA221
Relay 8 CQM1-OC221
Output
16 CQM1-OC222
Units
CQM1-OC224
Transistor 8 CQM1-OD211
Output
16 CQM1-OD212
Units
32 CQM1-OD213
CQM1-OD216
16 CQM1-OD214
8 CQM1-OD215
AC Output 8 CQM1-OA221
Units
6 CQM1-OA222
Model Input words
(starting from
IR 001)
1
1
1
2
2
2
1
1
---
Section 3-2
Output words
(starting from
IR 100)
---
1
1
1
1
1
2
2
1
1
1
1
153
