Pulse I/O Board
Examples
Pulse Output with Trapezoidal Acceleration/Deceleration and Separate
Acceleration/Deceleration Rates
The only limitation that exists is that ACC(––) (ACCELERATION CONTROL)
in Mode 0 (Acceleration + Independent) cannot be used in High-speed
Counter Mode.
Instruction PULS(65)
Function Sets number of
pulses
(Used in combination.)
High-speed Enabled
Counter
Mode
Simple Enabled
Positioning
Mode
The setting in DM 6611 is read only when the CQM1H is started. If this setting
is changed, the PC must be turned OFF and ON again to enable the new
value.
Operation Settings for Ports 1 and 2 (DM 6643 and DM 6644)
The diagram below shows how port 1 (DM 6643) and port 2 (DM 6644) are
set to perform fixed duty factor pulse output, which is the default pulse output
format. The settings for ports 1 and 2 can differ.
15
Bit
DM 6643
0
Port 1 Pulse Type
0: Fixed duty factor pulse output
Set to fixed duty factor when per-
forming standard pulse output.
1: Variable duty factor pulse output
Default: 0
(Fixed duty factor pulse output)
Variable duty factor pulses cannot be output from a port if it has been set to
perform standard pulse output.
The following examples show programs that controls pulse output from ports
1 and 2. Before running the programs, check that the settings in the PC Setup
are as follows:
DM 6611: 0001 (Simple Positioning Mode)
DM 6643: 0000 (Fixed duty factor pulse output from port 1)
DM 6644: 0000 (Fixed duty factor pulse output from port 2)
ACC(––)
Acceleration/ Stops pulse
Deceleration output
rates (separate
settings)
Sets frequency
Starts pulse
output
Mode 0 (Acc.+ Enabled
Independent):
Disabled
Mode 3:
Enabled
0 15
Bit
DM 6644
0
Port 2 Pulse Type
0: Fixed duty factor pulse output
Set to fixed duty factor when per-
forming standard pulse output.
1: Variable duty factor pulse output
Default: 0
(Fixed duty factor pulse output)
Section 2-2
INI(61) PRV(62)
Reads pulse
output status
0
