Timer and Counter Instructions
CTBL(63) Table
Comparison
PV Change
256
C P1
000 000
001 000
002 New high-speed counter PV
003 000
The following table shows which values of C can be used with each function.
Unit/Board
CPU Unit
Transistor Output Unit
Pulse I/O Board
Absolute Encoder
Interface Board
High-speed Counter
Board
If C is 000 or 001, INI(61) starts or stops comparison of the high-speed
counter's PV to the comparison table registered with CTBL(63). Refer to 1-4-6
High-speed Counter 0 Interrupts for details on table comparison.
If C is 002, INI(61) changes the high-speed counter's PV to the 8-digit value in
P1 and P1+1. The leftmost 4 digits are stored in P1+1 and the rightmost 4 dig-
its are stored in P1. A hexadecimal value of F in the most significant digit of
PV indicates that the PV is negative.
CPU Unit: Built-in High-speed Counter 0
The following table shows the possible 8-digit BCD values for the PV of high-
speed counter 0.
Mode
Differential phase mode
Incrementing mode
Pulse I/O Board: High-speed Counters 1 and 2
The following table shows the possible 8-digit BCD values for the PV of high-
speed counters 1 and 2 on a Pulse I/O Board.
Numeric range
Linear counting
Ring counting
Absolute Encoder Interface Board: High-speed Counters 1 and 2
The PV of absolute high-speed counters 1 and 2 cannot be changed.
High-speed Counter Board: High-speed Counters 1 to 4
The following table shows the possible 8-digit values (BCD or hexadecimal)
for the PV of high-speed counters 1 to 4 on a High-speed Counter Board.
Numeric range
Linear counting F838 8608 to 0838 8607
Ring counting 0000 0000 to 0838 8607
Starts CTBL(63) table comparison.
Stops CTBL(63) table comparison.
Changes high-speed counter PV.
Stops pulse output.
Function
High-speed counter 0
Pulse output
High-speed counters 1 and 2
Pulse outputs 1 and 2
Absolute high-speed counters
1 and 2
High-speed counters 1 to 4
Possible values
F003 2768 to 0003 2767
0000 0000 to 0006 5535
Possible values
F838 8608 to 0838 8607
0000 0000 to 0006 4999
Possible values
BCD format
Section 5-16
INI(61) function
Values of C
000 001 002 003
YES YES YES ---
--- --- --- YES
YES YES YES ---
--- --- --- YES
YES YES --- ---
YES YES YES ---
Hexadecimal format
F800 0000 to 07FF FFFF
0000 0000 to 07FF FFFF
