Active Points Alarms and Event Log

Active Point Alarms
Active Point Alarms appear on the TD7 display immediately upon detection. Touch the Active Point
Alarms to view the Active Point Alarms.
Figure 22
alarm clears and the point returns to normal, the alarm will automatically be removed from the list.
The number of active point alarms is displayed in the top right portion of the screen.
For the point alarms to appear on the TD7 display, the point must have an alarm notification class
selected other than None when it was set up in Symbio™ UI or Tracer
must have entered the appropriate notification (In Alarm, When Failed, Return to Normal, or the
notification class set to a value other than None).
Figure 22. Active Point Alarms screen
Sortable Columns
Event Log
Touch the Event Log to view the Event Log.
Point Alarm icons appear in the left-most column of the Active Point alarms and Event Log screens.
They are identifiable by their shape and color.
Figure 23
For the events to appear on theTD7 display, the point must have an alarm notification class selected
other than None when it was set up in Symbio™ UI or Tracer
entered the appropriate notification (In Alarm, When Failed, Return to Normal, or the notification
class set to a value other than None).
RT-SVP011E-EN
shows the Active Point Alarms screen and commonly used functions. When the point
Alarm Severity
shows the Event Log screen and commonly used functions.
TD7 Display
®
TU. Additionally, the point
Number of Active
Point Alarms
®
TU. Additionally, the point must have
25
