Link Aggregation Screen (802.3ad Main Menu Screen)
Screen Example
Figure 6-10 802.3ad Port Details Screen
Field Descriptions
Refer to Table 6-9 for a functional description of each screen field.
Table 6-9 802.3ad Port Details Screen Field Descriptions
Use this field...
Port Instance
(Read-Only)
ActorSystemPriority
(Modifiable)
ActorPort
(Read-Only)
ActorSystemID
(Read-Only)
6-32 Port Configuration Menu Screens
To...
See the port number, which correlates to the port numbers in
screens.
other
Set the system priority associated with this port for use used
in the construction of the LAG ID of the port.
See the identifier for this port (identical to Port Instance).
See the System Identifier for the system in which this port
resides.
