Menu Descriptions
Refer to Table 5-1 for a functional description of each menu item.
Table 5-1 Module Configuration Menu Screen Menu Item Descriptions
Menu Item
GENERAL
CONFIGURATION
SNMP
CONFIGURATION
MENU
SYSTEM
RESOURCES
INFORMATION
FLASH
DOWNLOAD
CONFIGURATION
PORT
CONFIGURATION
MENU
802.1
CONFIGURATION
MENU
LAYER 3
EXTENSIONS
MENU
Screen Function
Used to monitor and configure the switch module operating
parameters. For details, refer to
Used to access the SNMP Community Names Configuration, SNMP
Traps Configuration, and Access Control List screens. These screens
are used to modify SNMP community names, set SNMP traps and
provide additional security while managing the modules. For details,
refer to Section 5.3.
Displays the CPU type used in the module and its operating speed;
displays the size of each memory system used (FLASH memory,
DRAM and NVRAM) in the module and the unused portion of each
memory; and displays the current CPU (switch) utilization and the
peak switch utilization. For details, refer to
Used to force the switch module to download a new image file from a
TFTP server to its FLASH memory. For details, refer to
To prevent passwords from being downloaded and overwriting the
current passwords in memory, refer to the Security screen information
described in Section
Used to select the screens for configuring the switch module ports. For
details, refer to Section
Provides access to the Spanning Tree Configuration Menu screen, the
802.1Q VLAN Configuration Menu screen, and the 802.1p Priority
Configuration Menu screen. For details, refer to
Provides access to the IGMP/VLAN Configuration screen to configure
ports and VLANs to operate according to the Internet Group
Management Protocol (IGMP). For details, refer to
Module Configuration Menu Screen
Section 5.2.
3.7.
6.1.
Module Configuration Menu Screens
Section 5.7.
Section
Section 7.1.
Chapter 10.
5.8.
5-3
