Link Aggregation Screen (802.3ad Main Menu Screen)
Table 6-10 802.3ad Port Statistics Screen Field Descriptions
Use this field...
Port Instance
(Read-Only)
LACPDUsRx
(Read-Only)
IllegalRx
(Read-Only)
MarkerPDUsRx
(Read-Only)
LACPDUsTx
(Read-Only)
MarkerResponsePDUsRx
(Read-Only)
MarkerPDUsTx
(Read-Only)
UnknownRx
(Read-Only)
MarkerResponsePDUsTx
(Read-Only)
RxState
(Read-Only)
6-38 Port Configuration Menu Screens
To...
See a unique number used to identify this port. This corresponds
to the port numbering scheme seen in other screens.
See the number of valid Marker PDUs that this Aggregation Port
can receive.
See the number of received frames carrying the Slow Protocol's
Ethernet Type value (34B.4), and also contain a badly formed
PDU or a value of Protocol Subtype (43B.4) that is illegal.
See the number of valid Marker Response PDUs that this
Aggregation Port can receive.
See the number of LAC PDUs that this Aggregation Port can
transmit.
See the number of Marker Response PDUs that this Aggregation
Port can transmit.
See the number of Marker PDUs that this Aggregation Port can
transmit.
See the number of Unknown frames that can be received that
either
•
carry the Slow Protocols Ethernet Type value but contain an
unknown PDU, or
•
are addressed to the Slow Protocols group MAC Address but
do not carry the Slow Protocols Ethernet Type.
This is a 32-bit counter of the number of Unknown frames
received, so the value can range from 0 to 2^32-1 (or 0 to
4,294,967,296).
See the number of Marker Response PDUs that this Aggregation
Port can transmit.
See the state of the Receive state machine for this port.
