Priority Classification Configuration Screen
Table 9-6 Priority Classification Configuration Screen Field Descriptions (Continued)
Use this field ...
PID
– bottom of screen
(Modifiable)
CLASSIFICATION
– bottom of screen
(Selectable)
ADD
– bottom of screen
(Toggle)
DEL ALL/DEL
MARKED
– bottom of screen
(Toggle)
9-18 802.1p Configuration Menu Screens
To...
Enter the priority value that will be associated with the classification
selected in the Classification field. A PID from 0 to 7 may be typed
into the field, where 0 is the lowest priority and 7 is the highest priority.
Select the classification that will be associated with the priority
selected in the PID field. Depending on the classification selected,
there can be up to three fields involved (CLASSIFICATION, IP
ADDRESS, and MASK). At the time of this printing, the selections
available in each field are listed in
NOTE: Besides the PID selected, the order in which a frame is
transmitted also depends on the Classification Precedence
Rules discussed in
when there are multiple classifications configured in the switch
module.
For details on how to use the Priority Classification Configuration
screen to select the Classification rule, refer to
Add the current Classification Rule (PID and Classification selections)
to the screen.
Delete all or one or more marked entries, simultaneously. The DEL
ALL command is the default and it is used to simultaneously delete all
the configured information Classification Rules. The DEL MARKED
command appears in place of the DEL ALL command when one or
more lines are marked for deletion.
Table 9-7.
Section 9.6.1. These rules come into effect
Section 9.6.4.
