NOTE: The screens described in this chapter apply only to the 6C105 chassis.
This chapter provides the information to access the following:
•
Chassis Configuration screen to set the chassis operating parameters
•
SNMP Configuration Menu screen and its menu items to access other screens to modify the
SNMP community names and set SNMP traps
•
Chassis Environmental Information screen to monitor the power supply status, power supply
redundancy status, and the fan tray status
•
Redirect Configuration Menu screen and its menu items to access other screens to configure the
chassis to redirect traffic from a source switch port to a destination switch port, or redirect traffic
from a VLAN to a particular switch port
Screen Navigation Path
For 6C105 chassis only:
Password > Main Menu > Chassis Menu
Chassis Menu Screens
(Section
4.3),
(Section
4.6), or
(Section
4.7).
(Section
4.2),
Chassis Menu Screens
4
4-1
