Port Configuration Menu Screen

6.1 PORT CONFIGURATION MENU SCREEN
When to Use
To select screens to perform port configuration tasks on the switch module.
How to Access
Use the arrow keys to highlight the PORT CONFIGURATION MENU item on the Module
Configuration Menu screen and press ENTER. The Port Configuration Menu screen,
displays. The list of menu items differs depending on the Aggregation (Agg) Mode selected in the
General Configuration screen described in
If the Agg Mode "HUNTGROUP" is selected in the General Configuration Menu screen, the Port
Configuration screen shown in
If the Agg Mode "IEEE8023ad" is selected in the General Configuration Menu screen, the Port
Configuration screen shown in
Screen Example
Figure 6-1 Port Configuration Menu Screen (in Agg Mode, HUNTGROUP)
6-2 Port Configuration Menu Screens
Section
Figure 6-1, displays.
Figure 6-2, displays.
5.2.
Figure 6-1,
