Ethernet Port Configuration Screen
Table 6-3 Ethernet Port Configuration Screen Field Descriptions (Continued)
Use this field...
Advertised Ability
(Selectable)
6-10 Port Configuration Menu Screens
To...
Select the port "advertised" mode of operation. In normal operation,
with all capabilities enabled, the port "advertises" that it has the ability
to operate in any mode. The user may choose to set up the port so that
only a portion of the available capabilities are advertised and the others
are disabled. The left field displays the advertised ability of the port,
but only becomes active on ports that have Auto-Negotiation enabled.
The status of a particular ability is displayed in the right field. The "T"
in an ability stands for twisted pair. The possible abilities are listed
below. Only those abilities that are supported will be available.
10Base-T – 10 Mbps operation
10Base-TFD – 10 Mbps full duplex operation
100Base-TX – 100 Mbps operation
100Base-TXFD – 100 Mbps full duplex operation
1000Base-X – 1000Base-SX, 1000Base-LX Gigabit Ethernet
1000Base-T – 1000 Base-T Gigabit Ethernet
1000Base-XFD – 1000Base-SX, 1000Base-LX Full Duplex Gigabit
Ethernet
1000Base-TFD – 1000Base-T Full Duplex Gigabit Ethernet
FDX PAUSE – Symmetric PAUSE operation for 10/100 Mbps Ethernet
ports in full duplex
FDX APAUSE – Asymmetric PAUSE operation for full-duplex links in
Gigabit Ethernet
FDX SPAUSE – Symmetric PAUSE operation for full-duplex links in
Gigabit Ethernet
FDX BPAUSE – Asymmetric and Symmetric PAUSE operation for full
duplex links in Gigabit Ethernet
Rem Fault 1 – simple fault or error detection is supported
Rem Fault 2 – simple fault or error detection is supported
To enable or disable advertised modes, refer to Section 6.3.2.
