Port Redirect Configuration Screen
Screen Example
Figure 4-8 Port Redirect Configuration Screen
Field Descriptions
Refer to Table 4-8 for a functional description of each screen field.
Table 4-8 Port Redirect Configuration Screen Field Descriptions
Use this field...
Source Module
(Read-Only)
Source Port
(Read-only)
Destination Module
(Read-Only)
Destination Port
(Read-only)
4-20 Chassis Menu Screens
To...
See which modules are currently set as source modules.
See which ports are currently set as source ports.
See which modules are currently set as destination modules.
See which ports are currently set as destination ports. Only one
destination port may be assigned to a source port.
