Mac Supplicant Configuration Screen Field Descriptions - Enterasys SmartSwitch 6000 User Manual

Screen Example
Figure 3-19 MAC Supplicant Configuration Screen
Field Descriptions
Refer to Table 3-17
Table 3-17 MAC Supplicant Configuration Screen Field Descriptions
Use this field...
Port
(Read-Only)
Duration
(Read Only)
MAC Address
(Read Only)
for a functional description of each screen field.
To...
See the port numbers of all ports known to the device. Up to 10 ports
can be displayed at a time. To see additional ports, select NEXT and
press ENTER to display the authentication type and status for the next
10 ports.
See the time in days:hours:minutes:seconds that an active supplicant is
logged on via the port.
See the ASCII value of the MAC address for each active supplicant
associated with a port.
MAC Supplicant Configuration Screen
Accessing Local Management 3-57
