SNMP Traps Configuration Screen

To establish community names, proceed as follows:
1. Use the arrow keys to highlight the Community Name field adjacent to the selected access
level.
2. Enter the password in the field (maximum 31 characters).
3. Press ENTER.
4. Repeat steps 1 through 3 to modify the other community names.
5. Use the arrow keys to highlight SAVE at the bottom of the screen and press ENTER. The
message "SAVED OK" displays. The community names are saved to memory and their access
modes implemented.
4.5 SNMP TRAPS CONFIGURATION SCREEN
When to Use
To configure the chassis to establish which workstations are to receive trap alarms, the trap
message to be sent to the Network Management Station, and also set the trap function to on or off
as needed. Since the 6C105 chassis is an SNMP compliant device, it can send messages to multiple
Network Management Stations to alert users of status changes.
How to Access
Use the arrow keys to highlight the SNMP TRAPS CONFIGURATION menu item on the
SNMP Configuration Menu screen, and press ENTER. The SNMP Traps Configuration screen,
Figure 4-5, displays.
4-14 Chassis Menu Screens
