VLAN Redirect Configuration Screen
4.9.1

Changing Source VLAN and Destination Ports

To add or delete source VLAN and destination port entries and set the Frame Format and Redirect
Errors functions, proceed as follows:
1. Use the arrow keys to highlight the Src VLAN ID field near the bottom of the screen.
2. Press the SPACE bar or BACKSPACE key one or more times to increment or decrement the
VLAN ID number displayed in the brackets [n] until the desired VLAN ID number displays.
3. Use the arrow keys to highlight the Src Module field near the bottom of the screen.
4. Use the SPACE bar or BACKSPACE key to step to the desired module number for the
destination module.
5. Use the arrow keys to highlight the Dest Port field near the bottom of the screen.
6. Press the SPACE bar or BACKSPACE key one or more times to increment or decrement the
port number displayed in the brackets [n] until the desired VLAN ID number displays.
7. Use the arrow keys to highlight the Dest Module field near the bottom of the screen.
8. Use the SPACE bar or BACKSPACE key to step to the desired module number for the
destination module.
9. Use the arrow keys to highlight the Frame Format field near the bottom of the screen.
10. Use the SPACE bar or BACKSPACE key to step to the desired frame format setting
(RECEIVED, TAGGED, or UNTAGGED) for the selected Destination Port.
11. Use the arrow keys to highlight the Status field.
12. Use the SPACE bar to select either the ADD or DELETE option. Press ENTER. This adds or
deletes the selections for the Source VLAN, Destination Port, and Frame Format made in steps
1 through 10 and also updates the screen. If an entry is being changed, delete the entry, save the
screen, then recreate the entry with its new settings.
TIP: If more than 1 port is being redirected, repeat steps 1 through 12 for each
additional setting. Then go to step 13 to save all the new settings at once.
If an entry is to be changed, delete the entry, save the screen, then recreate the entry
with its new settings.
Any combination, up to 128, of port redirect instances (configured on the Port Redirect
Configuration screen) and/or VLAN redirect instances (configured on the VLAN Redirect
Configuration screen) can be configured.
13. Use the arrow keys to highlight SAVE at the bottom of the screen. Press ENTER. The message
"SAVED OK" displays. This saves the new settings and updates the Source VLAN and
Destination Port read-only fields.
4-26 Chassis Menu Screens
