Spanning Tree Configuration Screen

Table 7-2 Spanning Tree Configuration Menu Screen Menu Item Descriptions (Continued)
Menu Item
PVST PORT
CONFIGURATION
7.3 SPANNING TREE CONFIGURATION SCREEN
CAUTION: This screen should be used only by personnel who are very knowledgeable
about Spanning Trees and how to develop them. Otherwise, the proper operation of the
network could be at risk.
When to Use
To create a separate Spanning Tree topology for each VLAN configured in the switch module.
Also provides access to the PVST Configuration screen.
How to Access
Use the arrow keys to highlight the SPANNING TREE CONFIGURATION menu item on the
Spanning Tree Configuration Menu screen, and press ENTER. The Spanning Tree Configuration
screen, Figure 7-3, displays.
7-6 802.1 Configuration Menu Screens
Screen Function
Used to allow Multiple Spanning Trees.
This screen displays when you select a port of interest on the Spanning
Tree Port Configuration screen. For details, refer to Section 7.5
