Field Descriptions
Refer to Table 8-6 for a functional description of each screen field.
Table 8-6 VLAN Port Configuration Screen Field Descriptions
Use this field...
Policy PVID
Override is
(Read-Only)
Global GVRP State
(Toggle)
Port
(Read-Only)
PVID
(Modifiable)
Port Mode
(Selectable)
Acceptable Frame
Types
(Toggle)
To...
See the active override to a port as a result of an application policy.
When a port number has an asterisk next to it, selecting that Port field
will cause this field to display with the application policy number.
There are two sources of an override; 1) default policy, and 2)
authenticated policy.
Authentication using 802.1X is not possible on a port in override mode.
In Figure 8-7, the override shown is 2.
Enable or Disable the GVRP Status. GVRP and PVST are not
interoperable. When ENABLED, GVRP is turned on for the entire
switch. When DISABLED, the VLANs are not learned on a given port.
See a list of the switch ports.
NOTE: In some cases this field may have an asterisk next to
it. It indicates that it is currently overridden by a policy.
If a port with an asterisk is highlighted using the curser, the policy
override is setting is displayed in the upper left-hand corner of the
screen as shown in Figure
Change the PVID of one or more ports. The value must be typed in the
field. This associates the port to the VLAN associated with the PVID.
See the current operational port mode and select one of the modes:
HYBRID, 1Q TRUNK, or 1D TRUNK. The default is HYBRID.
Set the port to receive all frames or only tagged frames. The selection
can be toggled to either ADMIT ALL FRAMES or ADMIT TAGGED
FRAMES ONLY.
If a port is to be connected directly to the computer of a user, printer, or
other device, set this to ADMIT ALL FRAMES.
If a port is going to be used for a trunk port connection to another
switch, set this to ADMIT TAGGED FRAMES ONLY.
VLAN Port Configuration Screen
8-7.
802.1Q VLAN Configuration Menu Screens 8-19
