Screen Example
Figure 6-3 Ethernet Interface Configuration Screen
Field Descriptions
Refer to Table 6-2 for a functional description of each screen field.
Table 6-2 Ethernet Interface Configuration Screen Field Descriptions
Use this field...
Intf
(Read-Only)
Port
(Read-Only)
PortType
(Read-Only)
To...
See the interface number.
See the number of the physical port on the interface. For the front panel
ports on the switch module, this will always be 1.
See the type of interface using the name of the physical port type. For
the Ethernet 10/100 Mbps ports in the switch module, FE-100TX will
be displayed. If a Fast Ethernet port is installed via an optional HSIM,
the interface displayed may be FE-100TX or FE100-FX. If a Gigabit
port is installed via an optional VHSIM, the interface displayed may be
GE-1000SX, GE-1000LX, or GE-1000CX.
Ethernet Interface Configuration Screen
Port Configuration Menu Screens 6-5
