308 C 11: M
HAPTER ANAGED
A P C
CCESS OINT OMMANDS
Table 56 Output for display ap status (continued)
Field
Radio 1 type
Radio 2 type
operational channel
operational power
base mac
bssid, ssid
Description
802.11 type and configuration state of the radio.
The configure succeed state indicates that the MAP has
received configuration parameters for the radio and the
radio is ready to accept client connections.
802.11b protect indicates that the 802.11b/g radio is
sending messages to 802.11b devices, while sending
802.11g traffic at higher data rates, to inform the
802.11b devices about the 802.11g traffic and reserve
bandwidth for the traffic. Protection mode remains in
effect until 60 seconds after the last 802.11b traffic is
detected by the 802.11b/g radio.
Sweep Mode indicates that a disabled radio is
nonetheless participating in rogue detection scans. Even
though this message appears only for disabled radios, all
radios, enabled or disabled, participate in rogue
detection.
Countermeasures Enabled indicates that the radio is
sending countermeasures packets to combat a rogue.
The following information appears for external antennas:
External antenna detected, configured as
antenna-model—Indicates that an external antenna has
been detected, and lists the antenna model configured
on the radio. (MSS does not detect the specific model.)
External antenna detected, not configured—Indicates
that an external antenna was detected but no external
antenna is configured on the radio.
External antenna not detected, configured as
antenna-model—Indicates that an external antenna is
configured on the radio but no external antenna was
detected.
The channel on which the radio is currently operating.
If the channel number is followed by (Auto), the value was
set by RF Auto-Tuning.
The power level at which the radio is currently operating.
If the power setting is followed by (Auto), the value was set
by RF Auto-Tuning.
Base MAC address of the radio.
SSIDs configured on the radio and their BSSIDs.
