Step-by-Step with the In-Wall Master Controller
16. After selecting all inputs,
scroll with the
arrow to highlight Next,
then press
<ENTER>
screen requests you to specify the Days you want the
event to happen.
17. Press the
<RIGHT>
press
<ENTER>
the day. Repeat the procedure for each day you want
to select.
18. Press the
<RIGHT>
continue advancing to the
right past Sa (Saturday).
The screen displays the
option to set the start time. You can select for a start
time of a Specific Time, at Sunrise, or at Sunset.
19. Press the
<RIGHT>
press
<ENTER>
your choice.
20. If you are selecting a specific time, scroll with the
<UP/DOWN>
get each number correct, press the
move to the next number.
21. Press the
<RIGHT>
to continue advancing
to the right. The screen
displays the option to set
a specific end time.
22. Scroll with the
you want. As you get each number correct, press the
arrow to move to the next number.
<RIGHT>
23. When finished setting end time, press the
arrow to select Done, then press
returns to the Main Menu screen, and automatically
exits programming mode in about 30 seconds if
there's no activity.
