Figure 3-1. Temporary Folder Setup Using Windows Desktop - Comtech EF Data TRP1000-OD Installation And Operation Manual

2. Create a temporary folder (subdirectory) on the user PC for the firmware archive download.
There are several ways the user may use create a temporary folder on a Windows-based PC:
a. Use the Windows Desktop to create and rename the temporary folder.
•
•
b. Use Windows Explorer to create and rename the temporary folder.
Updating Firmware
•
Drive letter 'c:' is used in these examples. Any valid, writable drive
letter can be used.
•
Typical for all tasks: Type the command without quotes, and then
press Enter to execute.
Right-click anywhere on the desktop to open the popup submenu, and then
select New > Folder to create the temporary folder. The new folder will be
created on the desktop.
Right-click on the new folder and then select 'Rename' from the popup submenu.
Rename this folder to "temp" or some other convenient, unused name.

Figure 3-1. Temporary Folder Setup using Windows Desktop

•
Select File > New > Folder to create the temporary folder. The new folder
will be created in the active folder.
•
Right-click the 'New Folder' folder name, and then rename this folder to
"temp" or some other convenient, unused name.
Figure 3-2. Temporary Folder Setup using Windows Explorer
TRP1000-4450 Troposcatter C-Band Outdoor Amplifier
3–3
Revision 0
MN-TRP1000-OD
