Parameters
4.3 Monitoring functions
Trip level, warning level
With active power monitoring, you can parameterize two different response levels (trip level /
warning level) for the upper and lower limits.
Trip level
• P> (upper limit)
• P < (lower limit)
Warning level
• P> (upper limit)
• P < (lower limit)
Active status of trip and warning levels
The trip level / warning level is active only when the motor is running, the startup procedure
has been completed and there is no test position feedback (TPF) (run+).
Response to trip level P> (upper limit), P< (lower limit)
Here, you can define the response of SIMOCODE pro in the event that the monitored
variable overshoots/undershoots the set trip level:
For further information, see also "Tables of responses of SIMOCODE pro" in Chapter
Important information (Page 7).
Table 4- 42
Response
Deactivated
signal
warn
tripping
Delay
Response to warning level P> (upper limit), P< (lower limit)
Here, you can define the response of SIMOCODE pro in the event that the monitored
variable overshoots/undershoots the set warning level:
For further information, see also "Tables of responses of SIMOCODE pro" in Chapter
Important information (Page 7).
Table 4- 43
Response
Deactivated
signal
warn
tripping
Delay
146
0.000 to 4294967.295 kW (default: 0.000 kW)
0.000 to 4294967.295 kW (default: 0.000 kW)
"Trip level" response for active power monitoring
"Warning level" response for active power monitoring
Trip level
X (d)
X
—
X
0 to 25.5 s (default: 0.5 s)
Warning level
X (d)
X
X
—
0 to 25.5 s (default: 0.5 s)
