3Com VCX V7000 Maintenance Manual page 144

144 C 9: C
HAPTER ONFIGURING THE
Table 12 CcTrusted Configurable Parameter Descriptions
Column Name Description
rowStatus This determines what sort of
configuration you want to do with a
trusted endpoint such as delete or add
one. In order to configure a row you
always need to specify the index.
index This is the trusted endpoint table's key
and is a unique identifier of a row.
TrustedAddress Indicates an endpoint to trust. Each
row is for an IP address and port
combination. By default, if only the IP
address is supplied, the default SIP IP
Port 5060 is assumed. To specify the
port, simply append a colon (:) to the
IP address and add the port number.
netmask Used when you would like to add a
range of trusted endpoints.
C P
ALL ROCESSOR
3 Start the remoteCLI interface:
./remoteCli -callprocessor
4 Add either a single or range of trusted endpoints:
a To add a single trusted endpoint, from the prompt (>) enter:
config CcTrusted rowStatus=4 index=<index ID>
TrustedAddress=<IP address of endpoint>
b To add a range of trusted endpoints using abbreviated variables, at the
prompt (>) enter:
config cct row=4 index=<index ID> trustedaddr=<IP address
of endpoint> netmask=<IP address of netmask>
See Table 12 for descriptions and values of the configurable parameters.
5 To exit the Remote CLI application, enter:
exit
When Takes
Effect Range
Once Call 1 = active
Processor 2 = not in service
restarted. 3 = not ready
4 = add
5 = create and wait
6 = delete
Once Call 1 through 128
Processor
restarted.
Once Call For IP Address:
Processor
dotted IP string
restarted.
NOTE: maximum 15
characters.
For Port Number:
0 through 65535
Once Call dotted IP string
Processor
NOTE: maximum 15
restarted.
characters.
Default
1
1
For IP Address:
0.0.0.0
NOTE: must be
configured.
For Port
Number:
5060
0.0.0.0
