Transfer Current Setting; Setting Of Rotation Time Before Toner Supply; Copy Density Adjustment(300Dpi) - Sharp AR-M207 Service Manual

Main Sub
code code
44 34

Transfer current setting

Used to set the transfer current value. When this simulation is executed, the list of modes and the current set
value are displayed on the LCD.
Sim44-34 TC
1:NML F
2:NML R
3:SML F
1/2 [ 9- 36]
Select a set item with the cross key and enter a set value with 10-key. Press [OK] key or [START] key, and
the set value is saved in the EEPROM.
The setting range is 90µA - 360µA. The calculation formula is "Set value x 10 (µA)."
For example, in order to set the transfer current value to 200µA, set the adjustment value to "20."
Display mode
NML F
NML R
SML F
SML R
BYPASS
[ ]: Default
* Small size paper means A4R (Letter R) width or less.
* When selecting the special size of tray, the normal size width setting is made.
40

Setting of rotation time before toner supply

Used to set the time from starting rotation of the main motor to starting toner supply when initializing after
turning on the power.
Sim44-40 TONER
1:ROTATE TIME
[ 1-
[1] - [99] (Default : [8] (Unit: sec))
Enter a set value with10-key and press [START] key. The set value is saved in theEEPROM and the
machine returns to the sub code input window.
46 01

Copy density adjustment(300dpi)

Used to set the copy density foe each exposure mode.
When this simulation is executed, the list of the setting items and the current set value are displayed.
Select an item to be changed with [ ] and [ ] keys and enter the adjustment value with 10-key.
The setting range is 1 - 99.
When [ ] or [
Enter the adjustment value with 10-key and press [OK] key. The entered value is saved in the EEPROM and
the machine shifts to the copy window.
Sample copying can be performed during the simulation
Sim46-1 EXP LEVEL
1:AE
2:TEXT
3:PHOTO 1
1/2 [ 1- 99]
Window display
1:AE
2:TEXT
3:PHOTO 1
4:PHOTO 2
5:TEXT (TS)
6:AE (TS)
ADJ. Sim44-34 TC
4:SML R
22
5:BYPASS
21
22
22 2/2
: Setting mode
: Normal size paper (Front) [22]
: Normal size paper (Back) [21]
: Small size paper (Front) [22]
: Small size paper (Back) [21]
: Manual paper pass [22]
8
99] 8
] key is pressed, the page is changed,.
Sim46-1 EXP LEVEL
50 4:PHOTO 2
5:TEXT(TS)
50
6:AE(TS)
50
2/2
50
: Adjustment mode
: AE MODE (300dpi)
: TEXT MODE (300dpi)
: PHOTO MODE (Error diffusion)
: PHOTO MODE (Dither)
: TS MODE (TEXT) (300dpi)
: TS MODE (AE) (300dpi)
AR-M207 M165 M162 SIMULATIONS 7-28
Contents
ADJ.
21
22
[ 9- 36] 22
50
50
50
[ 1- 99] 50
Remark
Default:
21(NML R, SML R)
22(NML F, SML F,
BYPASS)
Default:
8sec
