5.10.2 Welding task selection

•
Select JOB 128 (MMA welding task).
It is only possible to change the JOB number when no welding current is flowing.
Operating
element

5.10.3 Welding current setting

The welding current is normally set using the "Wire speed" rotary dial.
Operating
element

5.10.4 Arcforce

Operating
element
099-005323-EW501
21.05.2014
Action Result
Select JOB number input
1 x
Set the JOB number
The machine adopts the required setting after
approx. 3 seconds
Action Result
Welding current is set
Action Result
Select arcforcing welding parameter
LED for the button
Arcforcing setting for electrode types:
(Setting range -40 to 40)
Negative values
Values around zero Basic
Positive values
Design and function
is on.
Rutile
Cellulose
MMA welding
Display
Displays
Setpoint setting
Display
