MIG/MAG welding
•
Insert the central plug for the welding torch into the central connector and screw together with crown
nut.
•
Insert the plug on the workpiece lead into the "+" welding current connection socket and lock.
•
Welding current lead, insert polarity selection into the "-" welding current connection socket and lock.
•
Insert the welding torch control cable into the 19-pole connection socket and lock (MIG/MAG torches
with additional control cables only).
•
Lock connecting nipples of the cooling water tubes into the corresponding quick connect couplings:
Return line red to quick connect coupling, red (coolant return) and
supply line blue to quick connect coupling, blue (coolant supply).
To connect the positive wire electrode, follow the procedure in the "MIG/MAG standard
welding" chapter!
