Operating
element
After approx. 5 s without further user intervention, the set values are
adopted and the display switches back to the program display,
•
Key switch back to position "0"!
099-005323-EW501
21.05.2014
Action
Result
Press button until "PROG" LED comes
on.
x
Left:
Wire feed speed
n
Right:
Program number
Press button and hold down for approx.
4 s
4 s
Left:
Current limit value of the wire
feed speed correction
Right:
Current limit value of the
voltage correction
Set limit value for the wire feed speed
correction
Set limit value for voltage correction
Design and function
Special parameters (advanced settings)
Display (examples)
Left
Right
97
