5.8.16 Expert menu (MIG/MAG)

The expert menu includes functions and parameters which are either not set on the machine control, or
which do not require regular setting.

5.8.16.1 Selection

ENTER (Enter the menu)
•
Keep the "welding parameters" push-button pressed for 3 s.
NAVIGATION (Navigate the menu)
•
Select parameters by pressing the "welding parameters" push-button.
•
Set or change the parameters by turning the "welding parameter setting" rotary knob.
EXIT (Exit the menu)
•
After 3 s, the machine will return automatically to the ready-to-operate status.
099-005323-EW501
21.05.2014
ENTER NAVIGATION
3 s
Design and function
NOTE
Figure 5-39
MIG/MAG welding
EXIT
3 s
75
