■ SWR reading

The SWR meter ndcates the SWR over the trans-
msson lne n all modes.
q Push [TUNER] to turn the antenna tuner OFF.
w Push and hold [METER] (MF2) for 1 sec. to dsplay
mult-functon meter.
e Push [RTTY/PSK] once or twce to select RTTY
mode.
r Push [TRANSMIT].
t Rotate [RF POWER] clockwse past the 12 o'clock
poston for more than 30 W output power.
y Read the SWR on the SWR meter gage.
u Push [EXIT/SET] to close mult-functon meter.
The bult-n antenna tuner matches the transmtter to
the antenna when the SWR s lower than 3 : 1.

■ Screen type and font selections

2 types of screen mages and 3 types of frequency
readout ndcaton fonts are avalable n the IC-7600.
q Push [EXIT/SET] several tmes to close mult-func-
ton screen, f necessary.
w Push [SET] (F-6) to select set mode menu screen.
e Push [DISP] (F-3) to enter dsplay set mode.
r Push [Y] (F-1) or [Z] (F-2) to select "Dsplay
Type" tem when selectng the screen mage, select
"Dsplay Font" when selectng the frequency read-
out ndcaton font.
t Rotate the man dal to select the desred screen
mage or font.
• Screen mage s selectable from A (Black back) and B
(Blue back).
• Basc, Italc and Round are avalable for the frequency
readout font.
y Push [EXIT/SET] twce to ext from dsplay set
mode.
TRANSMIT TUNER METER
[RF POWER]
RTTY/PSK
Better than 1.5:1
F-1 F-2 F-3
DISP
• Screen image example—
Display Type: B, Display Font: Italic
11
MAINTENANCE
EXIT/SET
SET
F-6
Main dial
