Icom IC-7600 Instruction Manual page 156

Cmd. Sub cmd. Data
1A 05 0037 0000 to Send/read reference frequency
0255 (0000=0%, 0255=100%)
0038 0000 to Send/read LCD backlght brghtness level
0255 (0000=0% (dark), 0255=100% (brght))
0039 0000 to Send/read key backlght brghtness level
0255 (0000=0% (dark), 0255=100% (brght))
0040 00 Dsplay type A selecton
01 Dsplay type B selecton
0041 00 Basc font selecton
01 Italc font selecton
02 Round font selecton
0042 00 SLOW selecton for meter response
01 MID selecton for meter response
02 FAST selecton for meter response
0043 00 Standard meter selecton for normal screen
ndcaton
01 Edgewse meter selecton for normal screen
ndcaton
02 Bar meter selecton for normal screen ndca-
ton
0044 00 Edgewse meter selecton for wde screen
ndcaton
01 Bar meter selecton for wde screen ndcaton
0045 00 Meter peak hold functon for Bar meter OFF
01 Meter peak hold functon for Bar meter ON
0046 00 Memory name ndcaton OFF
01 Memory name ndcaton ON
0047 00 Audo peak filter wdth pop-up ndcaton OFF
01 Audo peak filter wdth pop-up ndcaton ON
0048 00 Manual notch filter wdth pop-up ndcaton OFF
01 Manual notch filter wdth pop-up ndcaton ON
0049 00 Screen saver OFF
01 15 mn. selecton for screen saver
02 30 mn. selecton for screen saver
03 60 mn. selecton for screen saver
0050 00 Bound selecton for screen saver type
01 Round selecton for screen saver type
02 Twst selecton for screen saver type
0051 00 Openng screen ndcaton OFF
01 Openng screen ndcaton ON
0052 see p. 158 Send/read openng screen contents.
0053 20000101 Send/read date
to ( 20000101=1st Jan. 2000,
20991231 20991231=31st Dec. 2099)
0054 0000 to Send/read tme
2359 (0000=00:00, 2359=23:59)
0055 00 Clock 2 OFF
01 Clock 2 ON
0056 see p. 157 Send/read offset tme for clock 2
0057 see p. 158 Send/read clock 2 name *Up to 3 characters
0058 00 Calbraton marker OFF
01 Calbraton marker ON
0059 00 Confirmaton beep OFF
01 Confirmaton beep ON
0060 00 Band edge beep OFF
01 Band edge beep ON (Beep sounds wth a
default amateur band)
02 Band edge beep wth user settng ON
03 Band edge beep wth user settng/TX lmt ON
0061 0050 to Send/read beep audo frequency
0200 (0050=500 Hz, 0200=2000 Hz)
0062 00 Auto selecton for [RF/SQL]
01 SQL selecton for [RF/SQL]
02 RF+SQL selecton for [RF/SQL]
0063 00 Quck dualwatch OFF
01 Quck dualwatch ON
0064 00 Quck splt functon OFF
01 Quck splt functon ON
0065 see p. 158 FM splt offset frequency settng for HF
0066 see p. 158 FM splt offset frequency settng for 50 MHz
0067 00 Splt lock functon OFF
01 Splt lock functon ON
0068 00 Tuner auto start OFF
01 Tuner auto start ON
Description Cmd. Sub cmd.
1A
CONTROL COMMAND
Data
05 0069 00 PTT tune OFF
01 PTT tune ON
0070 00 Antenna selecton OFF
01 Manual antenna selecton
02 Auto antenna selecton
0071 00 Transverter functons automatcally
01 Transverter functon ON
0072 see p. 158 Transverter offset frequency
0073 00 1275 Hz selecton for RTTY mark frequency
01 1615 Hz selecton for RTTY mark frequency
02 2125 Hz selecton for RTTY mark frequency
0074 00 170 Hz selecton for RTTY shft wdth
01 200 Hz selecton for RTTY shft wdth
02 425 Hz selecton for RTTY shft wdth
0075 00 RTTY keyng wth normal polarty
01 RTTY keyng wth reverse polarty
0076 00 1000 Hz selecton for PSK tone frequency
01 1500 Hz selecton for PSK tone frequency
02 2000 Hz selecton for PSK tone frequency
0077 00 Englsh selecton for voce syntheszer
speech language
01 Japanese selecton for voce syntheszer
speech language
0078 00 Speech speed slow
01 Speech speed fast
0079 00 S-meter level announcement OFF
01 S-meter announcement ON
0080 00 Operatng mode announcement (after push-
ng mode swtch) OFF
01 Operatng mode announcement (after push-
ng mode swtch) ON
0081 00 [SPEECH/LOCK] key functon settng
( Push momentarly=SPEECH,
Push and hold=LOCK)
01 [SPEECH/LOCK] key functon settng
( Push momentarly=LOCK,
Push and hold=SPEECH)
0082 00 Number of memo pad channels 5
01 Number of memo pad channels 10
0083 00 Auto TS for man dal OFF
01 Auto TS for man dal ON wth LOW
02 Auto TS for man dal ON wth HIGH
0084 00 LOW selecton for mcrophone Up/Down speed
01 HIGH selecton for mcrophone Up/Down speed
0085 00 Quck RIT/ : TX clear OFF
01 Quck RIT/ : TX clear ON
0086 00 Auto notch selecton for SSB operaton
01 Manual notch selecton for SSB operaton
02 Auto/Manual notch selecton for SSB operaton
0087 00 Auto notch selecton for AM operaton
01 Manual notch selecton for AM operaton
02 Auto/Manual notch selecton for AM operaton
0088 00 SSB/CW synchronous tunng functon OFF
01 SSB/CW synchronous tunng functon ON
0089 00 LSB selecton for CW normal sde set
01 USB selecton for CW normal sde set
0090 00 SHARP selecton for APF type
01 SOFT selecton for APF type
0091 00 Voce memory transmsson OFF wth exter-
nal keypad
01 Voce memory transmsson ON wth external
keypad
0092 00 Memory keyer transmsson OFF wth exter-
nal keypad
Memory keyer transmsson ON wth external
01
keypad
0093 00 RTTY memory transmsson OFF wth exter-
nal keypad
01 RTTY memory transmsson ON wth external
keypad
0094 00 PSK memory transmsson OFF wth external
keypad
01 PSK memory transmsson ON wth external
keypad
