Tx FunctOn; D ∂Tx MonTor FunctOn; Monitor Function - Icom IC-7600 Instruction Manual

4
RECEIVE AND TRANSMIT
■ ∂TX function
The ∂TX functon shfts the transmt frequency up to
±9.999 kHz n 1 Hz steps (10 Hz steps when cancel-
lng the 1 Hz step readout) wthout movng the receve
frequency.
q Push [∂TX] to turn ∂TX functon ON.
• " " and the shftng frequency appear when the
functon s ON.
w Rotate the [RIT/∂TX] control.
e To reset the ∂TX frequency, push and hold
[CLEAR] for 1 sec.
• Push [CLEAR] momentarly to reset the ∂TX fre-
quency when the quck RIT/∂TX clear functon s ON.
(p. 132)
r To cancel the ∂TX functon, push [∂TX] agan.
• " " and the shftng frequency dsappears.
When RIT and ∂TX are ON at the same tme, the
[RIT/∂TX] control shfts both the transmt and
receve frequences from the dsplayed frequency
at the same tme.
D ∂TX monitor function
When the ∂TX functon s ON, pushng and holdng
[XFC] allows you to montor the operatng frequency
drectly.
✔ For your convenience— Calculate function
The shft frequency of the ∂TX functon can be added/
subtracted to the dsplayed frequency.
➥ Whle dsplayng the ∂TX shft frequency, push
and hold [∂TX] for 1 sec.

■ Monitor function

The montor functon allows you to montor your trans-
mt IF sgnals n any mode. Use ths to check voce
characterstcs whle adjustng SSB transmt parame-
ter (p. 121).
The CW sdetone functons regardless of the
[MONITOR] swtch settng.
q Push [MONITOR] to turn the montor functon
ON and OFF.
• The ndcator on ths swtch lghts green when the mon-
tor functon s ON.
w Push and hold [MONITOR] to montor set mode.
e Rotate the man dal to adjust the montor level.
• Push and hold [DEF] (F-4) for 1 sec. to select a default
value.
r Push [EXIT/SET] to ext montor set mode.
NOTE: When usng the VOX voce delay, turn the
montor functon OFF; or transmtted audo wll be
echoed.
87
MONITOR F-4
DEF
• Monitor set mode
CLEAR
∂TX
[RIT/∂TX]
Appears
XFC
Main dial
EXIT/SET
