Set up the Control Head

Use the following instructions to power on the control head and confirm the
360 Imaging™ transducer and the GPS Receiver/Heading Sensor are detected by the
unit.
CAUTION! It is important to finish all installation connections before powering
on the control head. It may take up to a minute for the 360 Imaging™
transducer and other attached equipment to be detected by the control head.

1. Power on and Confirm Connections

1. Turn on the power source from the main switch.
2. On the control head, press the
on a control head in a multiple-control head Ethernet network, power on
the control head that is connected to the 360 Imaging™ Transducer
Deployment System first.
3. When the Title screen is displayed, press the MENU key to access the Start-
Up Options Menu.
4. Use the 4-WAY Cursor Control key to choose Normal, and press the RIGHT
Cursor key to select it.
5. Press and hold the VIEW key. Select System > Accessory Test. Confirm that
AS 360 and GPS + Heading Sensor are listed as Connected. It will take a
minute for the equipment to be detected.
6. Press and hold the VIEW key. Select System > GPS Diagnostic View. Confirm
that External GPS is displayed and the Fix Type indicates Enhanced or 3D.
NOTE: If the GPS Diagnostic View or Accessory Test is not displayed in the View Rotation,
press the MENU key twice to open the Main Menu. Select the Views tab > GPS Diagnostic
View or Accessory Test. Change the setting for each view to Visible.
Installation - Set up the Control Head
POWER/LIGHT key. If you are powering
