Install the Transducer Deployment System
Use the following instructions to install the Transducer Deployment System.
NOTE: Due to the wide variety of hulls, only general instructions are presented
in this installation guide. Each boat hull represents a unique set of requirements
that should be evaluated prior to installation. It is important to read the
instructions completely and understand the mounting guidelines before you
start the installation.
1
| Installation Overview
There are two mounting options available for installing the Transducer Deployment
System.
• Direct Transom Mount: Included
• Optional Mounting Brackets: If you do not want to mount the Transducer
Deployment System directly to the transom, you'll need a mounting bracket
to offset the unit from the back of the boat. For more information, visit
humminbird.com.
