• Transom Obstructions: Review the transom to confirm that you will not drill
into any obstructions (lines, hoses, gas tank, etc.) and that there is enough
space for the hardware to be installed.
• Space Above: Confirm that the boat's platform will not interfere with the
operation of the Transducer Deployment System.
• Power: The Transducer Deployment System is powered separately from the
control head. It must be connected to a switch where it can be powered on
when the boat is underway and powered off when it is docked. See Section
6. Route the Cables and Connect Power for more information.
• Cables: Test run the Ethernet cable from the chosen mounting location to the
control head (or optional Ethernet Switch). Test run the power cable from the
chosen mounting position to the main switch or fuse panel. The cable ports
are located at the top of the Transducer Deployment System, so it is important
to consider the distance and height required to route from the ports.
The cables should be routed through an established routing system on the
boat, in an area with minimal interference, without sharp edges, obstacles,
or obstructions that may damage the cables.
NOTE: To purchase Ethernet extension cables or an adapter cable, visit our Web
site at humminbird.com or call our Customer Resource Center for details at
1-800-633-1468.
19 Installation - Transducer
