5. Confirm the Baud Rate
If there is an accessory, such as an autopilot, connected to the Sensor pigtail cable
wires, you will need to confirm that the devices are communicating at the same baud
rate. The baud rate details are as follows:
• If the GPS Receiver/Heading Sensor is connected to the control head, and
NMEA Output is turned on, the control head will operate exclusively at a
baud rate of 38400. If there is an accessory attached to the Sensor's pigtail,
it also needs to operate at 38400. See your accessory installation guide to set
the baud rate to 38400.
• If NMEA Output is turned off, then baud rates 4800, 9600, and 38400 are
available on the control head and no further action is required.
Turn On/Off NMEA Output
1. Main Menu: Press the MENU key twice.
2. Select the Setup tab > NMEA Output.
3. Press the RIGHT or LEFT Cursor keys to select On or Off. (Default = Off)
NOTE: The menu option in your Fishing System will be called NMEA 0183 Output or
NMEA Output. If the menu option is not shown under the Setup tab, make sure the User
Mode is set to Advanced (Setup tab > User Mode > Advanced).

6. Set up the Network and Alarms

After you have confirmed all connections, the 360 Imaging™ transducer is ready to
use on the water. Proceed to your 360 Operations Manual to set up the depth source,
temperature source, and the 360 Imaging™ Alarms.
WARNING! If you will not be using the 360 Imaging™ Transducer on the water at this time,
continue to keep it powered while the boat is underway. This is critical to keep the pod
retracted. See Power Off for details.
Installation - Set up the Control Head
(for devices connected to the Sensor pigtail only)
40
