Silicon Graphics Altix XE320 User Manual page 228

D: System Specifications
Specification
Integrated I/O
Cluster interconnects
Node board dimensions
Chassis
Weight
System cooling
System input requirements
Power supply
BTU rating
Rack power requirements
200
Table D-1 SGI Altix XE320 System Specifications (continued)
Description
2 x InfiniBand® ports (1 per node), optional
2 x COM ports (1 per node)
2 x VGA ports (1 per node)
4 x Gigabit Ethernet ports (2 per node)
4 x USB ports (2 per node)
InfiniBand or Gigabit Ethernet
Two external 4X DDR InfiniBand port (optional)
Two external Gigabit Ethernet ports (one per node)
6.5 in. x 16.4 in. (165 mm x 417 mm)
1U rackmount
Dimensions:
Width: 17.2 in. (437 mm)
Height: 1.7 in. (43 mm)
Depth: 27.75 in. (705 mm)
Weight: 40 lb (18.2 kg)
Six high-performance 4-cm fans
AC Input Voltage: 100 - 240 VAC (North America/Japan/International)
Rated Input Current: 12A - 5A max
Rated Input Frequency: 50 to 60 Hz
Rated Output Power: 980 Watts
Rated Output Voltages: +12V @ 81A, +5V @ 4A
5173 BTUs/hr (for rated output power of 980 Watts)
Short rack: 8 kW
Tall rack: 32 kW
007-5466-001
