COM Port Address

BAUD Rate

Console Type

Flow Control

Console Connection

Continue CR after POST

Hardware Monitor

007-5466-001
This item enables you to specify which COM port to direct the remote console to: Onboard COM
A or Onboard COM B. This setting can also be Disabled.
This item enables you to set the BAUD rate for console redirection. The options are 300, 1200,
2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.
This item enables you to set console redirection type. The options are VT100, VT100,8bit,
PC-ANSI, 7bit, PC ANSI, VT100+, VT-UTF8, and ASCII.
This item enables you to select the flow control option for console redirection. The options are
None, XON/XOFF, and CTS/RTS.
This item enables you to decide how console redirection is to be connected: either Direct or Via
Modem.
Choose whether to continue with console redirection after the POST routine. The options are On
and Off.
Note: The BIOS automatically detects the type of CPU(s) and hardware monitoring chips that are
used on the motherboard and displays the Hardware Monitoring Screen accordingly. The
Hardware Monitoring Screen may look different than one shown on the following pages.
Advanced Setup
121
