A: BIOS Power-on Self Test
134
Shadow Ram Failed at offset:
Shadow RAM failed at offset nnnn of the 64k block at which the error was
detected.
System RAM Failed at offset:
System RAM failed at offset nnnn of in the 64k block at which the error was
detected.
Extended RAM Failed at offset:
Extended memory not working or not configured properly at offset nnnn.
System battery is dead - Replace and run SETUP
The CMOS clock battery indicator shows the battery is dead. Replace the
battery and run Setup to reconfigure the system.
System CMOS checksum bad - Default configuration used
System CMOS has been corrupted or modified incorrectly, perhaps by an
application program that changes data stored in CMOS. The BIOS installed
Default Setup Values. If you do not want these values, enter Setup and enter
your own values. If the error persists, check the system battery or contact SGI
technical support.
System timer error
The timer test failed. Requires repair of system board.
Real time clock error
Real-Time Clock fails BIOS hardware test. May require board repair.
Check date and time settings
BIOS found date or time out of range and reset the Real-Time Clock. May
require setting legal date (1991-2099).
Previous boot incomplete - Default configuration used
Previous POST did not complete successfully. POST loads default values and
offers to run Setup. If the failure was caused by incorrect values and they are not
corrected, the next boot will likely fail. On systems with control of wait states,
